GE104-32

7.3" DIA., Air Cooled, Belt Driven Alternator

Specifications
Net Rated Amperes 100 Amperes
Rpm Rated Amperes 3550
Preset Voltage Range 37.5 - 38.0 Volts DC
Full Load Voltage 35.5 (with 38.0 V. DC Preset Voltage)
Field Amps 4.5
Grounding Options ISOL., NEG., POS., Internal
Rotation Bidirectional
Shaft Diam 7/8"
Rpm Terminal Standard
Voltage Regulator Std Integral, Adjustable, Self-Exciting
Voltage Regulator Opt Remote, Adjustable, Self or Ignition Excited
Wiring Std 2-Wire
Wiring Opt 1-Wire (Internal Ground)
Diode Construction Individually Replaceable
Diode Capacity 225
GE104-32 GE104-32
