Net Rated Amperes |
100 Amperes |
RPM @ Rated Amperes |
4500 |
Preset Voltage Range |
37.5 - 38.0 Volts DC |
Full Load Voltage |
37 (with 37.5 V. DC Preset Voltage) |
Full Load Field Coil Amps |
4.5 |
Grounding Options |
ISOL., NEG., POS., Internal |
Rotation |
Bidirectional |
Shaft Diam. (Pulley I.D.) |
7/8" |
RPM Terminal |
Standard |
Voltage Regulator, STD. |
Integral, Adjustable, Self-Exciting |
Voltage Regulator, Optional |
Remote, Self or Ignition Excited |
Wiring, STD |
2-Wire |
Wiring, Optional |
1-Wire (Internal Ground) |
Diode Construction |
Individually Replaceable |
Diode Capacity, Amperes |
225 |
